Dual Systems Parameter :
Type
interactive whiteboard
CPU
Intel i3/i5/i7
OPS
win7/win10
Android OS
Android 5.1
Size
100''
Size of product
1514.8*102.6*934.7mm
Size of display
1652*930mm
Size of package
1942 x 1280 x 300 mm
N.W.(KGS)
85KG
G.W.(KGS)
Resolution
3840*2160(4K)
Display colors
8 bit/16.7 Billion
Capacity
≤300W
Respond time
8ms
Brightness
350(cd/m2)
Life time
≥60000h
Type of display
LED
Resolution ratio
32768(E)*32768(D)
Touch point
10 points
Max. viewing angle
178°
Contrast ratio
1200:1TYP
Working voltage
50-60HZ 100-240V
Standby power
3W
Working temperature
0~60℃
Panel
Samsung, LG or BOE
Touch accuracy
±2mm
Backlight
DLED
Power of speaker
8Ω10W*2
Recognizale object
≥Φ5mm opaque object
Glass type
tempering 4mm AG
Front ports
Infrared touch port*1;HDMI*1,PC-3.0*1;TV-USB2.0*1;Audio in*1;VGA*1;
Back android ports
RS232*1;MIC*1;Touch port *1;TF*1; USB2.0*2; HDMI*1;SPDIF*1;VGA out *1;VGA in *1; VGA Audio in*1; YPBPR*1;AV1*1;AV2*1;AV out*1;earphone*1;RF*1;WIFI*1;
Back PC ports
HDMI*1;USB3.0*2;USB2.0*2;VGA*1;network output*1;HDMI*1;USB3.0*2;USB2.0*2;VGA*1;network output*1;Microphone in*1
