21.5" Smart Touch Table

Code：	HS21.5AT
Panel：	LG/Samsung/BOE/Others
Color：	Black/Silver/White/Customized
Touch：	Infared Touch/Capacitive Touch/10 or 20 Touch Points
Material：	3mm Titanium-plated Silver Mirror

13800000000 Reservation Now

Data sheet

Product detail

Project case

Panel size	21.5"
Display area(mm)/mode	476x 268mm
Aspect Ratio	16:9
Maximum resolution	1920×1080
Display color	16.7M
Pixel Pitch(mm)	0.282(H)×0.282(V)
Brightness (nits)	250cd/m2
Contrast	1000:1
Visual angle	178°/178°
Response time	5ms
Life(hrs)	>50,000(hrs)
Touch Panel	Infrared 2-6 points touch/Capacitive 10-16 points touch
Positioning accuracy	±2mms
Transmittance	≥92%
Hardness	7H
Click manner	double point/multi-point(optional)
Response time	≤8ms
Output Resolution	4096X4096
Life time	Single point more than 600 million time
Input and output
VGA input	2
CVBS input	2
YPbPr input	1
TV	1
USB2.0	6
LAN	1
PC Audio	1
Audio input	1
Audio output	1
Speaker	2x10w
Video
Color system	PAL/NTSC/SECAM
Resolution support	480P/720P/1080P
OSD
Menu Language	Chinese/English
Computer
Motherboard	Intel H61
CPU	Intel Core i3 dual core
Graphcis card	Intergrated
Network card	Intergrated 10/100/1000M adaptive
Memory	4G DDR3
Hard Disk	128G SSD OR 500G SATA
WIFI/LAN	Support
Operate system	Windows 7/8/10
Power
Power supply	AC100V~240V,50/60Hz
Maximum power consumption	280W
Standby power consumption	3W
Temperature
Working temperature	0℃~50℃
Storage temperature	-10℃~60℃
Working humidity	20%~80%
Storage humidity	5%~95%
Appearance
Cabinet color/appearance	White, black, customized
Cabinet material	SPCC/Aluminum/Customized
Warranty	1year after shipping
