Size | | Model | 19.1 INCH | Display | 500.1*111.6mm | Resolution | 1920*360 | Brightness | 450 CD/M2 | Color | 16.7M | Contrast | 4000:1 | Power supply | 24v/ 5A | Warranty | 12 months | Viewing angle | 178/178 |
System | OS | Android | CPU | ARMⓇCortex™-A17 , Quad-core, 1.6GHz / PX30, ARM Cortex A53/ LCD Monitor ONLY/ Optional | GPU | ARM Mali-T764 500MHz | RAM | DDR3 1GByte | Storage | eMMC 8GByte | Network | LAN 10/100M Ethernet, Wi-Fi 802.11b/g/n (2.4GHz) | Bluetooth | BT 4.2 (Profile : A2DP, HID) | Connectivity | Micro USB 2.0 (Host 1ea, OTG 1ea) | Signal Output | Micro HDMI |
Touch (Optional) | I/O Ports | Micro USB 2.0 x 1 (OTG), Micro USB 2.0 x 1 (Host), DC 12V IN, Type C x 1, Micro HDMI Output, Reset x 1 | Latency (Φ8) | ≤ 45ms (Touch down), ≤ 35ms (Panning) | Multi Touch | ≤ 10 points | Power Supply | Input Power | AC100-240V@50/60Hz | Output Voltage | DC12V/20W | Output Current | 3A | Image | Decoder | JPEG, BMP, GIF, PNG | Encoder | JPEG | Video | Encoder | MPEG-1/2, MVC, GOOGLE VP8,H.263, MOTION JPEG | Decoder | VP8 | Audio | Decoder | MPEG Audio, WAV Audio, OGG Audio, FLAC Audio, MIDI Audio | Encoder | AMR Audio | Humidity | 10~80%RH | Temperature | 0°C~45°C | Storage | -20°C~60°C | Warranty | 12 month |
|
